Magnetic Stripe Reader

It's the ideal terminal for those who need reliable and resistant tool. Thanks to its small size, high continuity of work, drop resistance, WiFi and Bluetooth communications, the IT 8000 is suitable for any kind of requirement.



Optical System:

• Scan Speed: 100 ~1000mm per second
• Light Source: 660nm Visible RED or 940nm lnfra Red
• Resolution: 0.13mm (5 mil)
• PCS Value: 45% or more
• Depth of Field: 30 0-2mm
• Scanning Position: 11mm From Slot Bed



Electrical:

• Voltage: 5V DC+10%
• Operating Current: BSR-100K(1/F KB) : 120mA
• BSR-100R(1/F RS232) : 85mA
• BSR-100T(Wand Emulation) : 15mA



• Environmental:
  Temperature- Operating: 0 to +50°C
  Storage: -26 to +60°C
  Humidity- Operating: up to 80%RH
  Storage: up to 90%RH
  Ambient Light Rejection: 3000 Lux max. (Fluorescence)800 Lux max. (Sunlight)

Drcp testing:

• Approved by 1.2M drop test on concrete
• Safty approval: FCC Class-B , CE Class-B,EMC ,U/C CSA



Physical

Case Material:

• 30%PC +70% ABS, UL94U0
• Weight: 80g ,excluding cable and Connector
• Type of Cable: 1.5M straight cable



Dimension

• L: 107.5mm W: 31mm H: 37.5mm
